Auxbeam 5 inch V-MAX Series Side Shooter LED Pod Lights – White & Amber DRL
Built for superior visibility and all-terrain performance, the V-MAX Series LED Pod Lights combine a powerful front spot beam, dual side illumination, and amber DRL to deliver enhanced safety day and night.
Features
Side Shooter Wide-Angle Design
Equipped with dual side shooter LEDs working together with the front spot beam to expand lighting coverage, helping reveal road edges, obstacles, and hidden hazards for safer driving.
Ultra-Bright Performance
Powered by premium LED chips with 84W output per light and 8,220 lumens each, delivering brighter, wider, and longer-range illumination. Built for long-lasting performance with a lifespan exceeding 50,000 hours.
3 Lighting Modes for All-Day Safety
Multiple lighting options for different driving conditions:
- Main Light – Front spot beam + side shooter lighting for maximum nighttime visibility
- Amber DRL – Daytime running light for improved vehicle visibility
- Combined Mode – Main light + Amber DRL for enhanced safety and style
Easy Plug & Play Installation
Includes a complete DT connector wiring harness kit for fast installation with minimal effort.
Wide Vehicle Compatibility
Compatible with most 10–24V DC systems, including:
- Trucks
- Jeep
- Boats
- Trailers
- ATV / Off-road Vehicles
- 4×4
- SUV
- Motorcycles
- Construction Equipment
- Agricultural & Heavy-Duty Vehicles
Specifications
- Size: 5 Inch
- LED Configuration (Each): P8 5W × 15 + 3030 SMD 9W
- Power: 168W per Set
(Spot Light 75W + Amber DRL 9W × 2) - Brightness: 16,440LM Total
(Main Light 15,000LM + Amber DRL 1,440LM) - Beam Pattern: Spot Beam + Double Side Shooter
- Lighting Distance: 1lux @ 598m
- Color Temperature: 6900K White / 3000K Amber DRL
- Light Color: White + Amber DRL
- EMC/EMI Protection: Yes
- Housing Material: Aluminum Alloy
- Lens Material: PC
- Waterproof Rating: IP68
- Mounting Type: Universal (M10 Screw Mount)
- Operating Voltage: 10V–30V
(Included relay harness supports 12V only; replaceable for 24V systems) - Housing Color: Black
- Lifespan: 50,000+ Hours
